Online low frequency three phase 160kva ups uninterrutible power solution

FOB Reference Price:Get Latest Price
US $11,000-21,000 / Piece | 1 Piece/Pieces (Min. Order)
Supply Ability:
3000 Piece/Pieces per Month
Port:
Yantian, Shekou,Guangzhou
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
IWELL
Model Number:
I33E 160k
Phase:
Three Phase
Protection:
Overvoltage
Weight:
475KG
Output Voltage:
380Vac
Type:
On-line
Application:
Instrumentation
type:
160KVA/128KW
Low Frequency:
Yes
Rated Voltage & Range(V):
380V±25%
Display:
LCD+LED
UPS Size(W x H x D)mm:
1300x1900x900
input Voltage(V):
380V(Line Voltage)
Frequency & Range(Hz):
46Hz-54Hz
output Voltage(V):
380V(Line Voltage)
Tracking Fruquency & Range(Hz):
46Hz~64Hz
Output Power factor:
0.8(Lag)
Packaging & Delivery
Packaging Details
wooden packing
Delivery Time
10 - 15 working days



Product Description

Online low frequency three phase 160kva ups



Products Characteristic:

  1. Advanced DSP digital control technology
  2. Large-screen LCD + LED in Chinese and English display
  3. Dual AC input
  4. Parallel machine functions
  5. High loading capacity, shock stronger
  6. Charging current settable
  7. Intelligent battery management
  8. Adaptive system frequency and phase sequence
  9. Protection and alarming functions
  10. Especially for banks, telecom, government, transportation, manufacturing,
  11. education, sensitive devices, etc.



Specification:

I33E SERIES 100- 200Kva (3 phase in 3 phase out)
MODELI33E100KI33E120KI33E160KI33E200K
Input MainsRated Voltage(V)380V(Line Voltage)
Rated Voltage & Range(V)380V±25%
Frequency & Range(Hz)46Hz-54Hz
Bypass InputRated Voltage(V)380V(Line Voltage)
Rated Voltage & Range(V)380V±25%
Frequency & Range(Hz)46Hz-54Hz
OutputRated Power100KVA/80KW120KVA/96KW160KVA/128KW200KVA/160KW
Rated Voltage(V)380V(Line Voltage)
Rated Voltage & Stability380V±2%
THDV≤3%
≤10%
Output Power factor0.8(Lag)
Tracking Fruquency & Range(Hz)46Hz~64Hz
Fruquency & Stability(Battery Inverter)(50+0.1)Hz/60+0.1)Hz
Overload CapabilityLess than 105%±5% for overload alarm;
105%±5%~125%±5% for 2 minutes;
125%±5%~150%±5% for 30 second;
More than 150%±5% for 0.5 second;
Converting time(Normal Mode)<1mS
Converting time(ECO Mode)<25mS
SystemSystem Efficiency(Linear Load)≥90%
DisplayLCD+LED
EMS/EMITransmissionIEC EN62040-02
Radiation
ResistingIEC 61000-4-2.4.5 Level IV, IEC61000-4-3 Level III
Interference
Safety RequirementsGB4943-2001/IEC62040-1
Noise Level(1M)≤70dB
Isolate Impedance(Ω)>2M(500VDC)
Surge Current ProtectionIEC60664-1 IV
Operating Temperature0°C - 40°C
Elevation<1000m
Storing Temperature-15°C - 45°C
Operation Humidity20% - 95%
Battery384VDC
UPS Size(W x H x D)mm850x1600x800 / 1300x1900x900
Package Size(WxHxD)mm920x1777x870 / 1380x2055x986



Packaging & Shipping
  1. Payment T/T,L/C, western union and money gram
  2. T/T 30% deposit, balance in full before shipment
  3. Packing Color box+plastic bags+carton / as customer request
  4. Warranty 1 year







Company Information



Shenzhen Zhongyuan Chuangda Technology Co. Ltd (ZYUPS), with our brand IWELL,was founded in 1997. we are a professional high-tech high precision and high quality enterprise with international trade experience specialized in the development manufacture sale and after-sales service of UPS (Uninterrupted Power System), solar inverter and Storage Lead Acid Battery.



To fit the varieties of customers and markets we offer Offline UPS ranges high frequency Low frequency Rack-mounted and line interactive UPS range. Home inverter, solar inverter with and without MPPT PMW controller.Our IWELL products have passed ISO9001 also with CE UL ROSH FCC certificate.



Innovative technology is our pursuit target. Our R&D center (research and development center) located in shenzhen. With first-class research and development conditions Strong R&D team research and development ability ensure that the products of advanced and innovative. continuously introduce more market competitive model to meet customers High reliability and high intelligent demands.



With the notion of "close to customer" we have aligned most of our resources to support our Original Equipment Manufacturer (OEM) customers and work with our customers as a power partner. Our mission is " faith cooperation pragmatic innovation and development " and to accomplish this we will continue to tailor products for market needs while maintaining high quality integrated customer service and prompt delivery.







Certifications



FAQ

Q:What's the payment term?

A:We accept TT,30% deposit and 70% balance against copy of B/L.



Q:How is the delivery time?

A:Usually it will take about 25 working days for production



Q:How is the standard of the package?

A:For the small capacity,it will use cartoon,for the big capacity,we should use the strong wooden case for protection.



Q:Would you accept our own logo?

A:If you have good quantity,it's absolutely no problem to do OEM.



Q:Could you tell me the month capacity?

A:It depends on the model,for example,the relay type small capacity,month capacity can reach near 20000pcs and big capacity near 30000pcs.



Q:Does the inverter connect with solar system?

A:Yes,because of the unique feature which combine invert,charge and ac auto-transfer switch into one complete system,made inverter not only connect with solar system,but also could used in officer equipment,household items,power tools etc
