Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: IWELL
  • Model Number: IA-6K
  • Phase: Single Phase
  • Protection: Overvoltage
  • Weight: 160KG
  • Output Voltage: 220v
  • Type: On-line
  • Application: Security / Monitoring / Alarm
  • Rated Power: 6KVA/4.8KW
  • Wave form: pure sine wave
  • Power factor: 0.8/0.9
  • Rated Voltage & Range(V): 220V±25%
  • input Voltage(V): 220V(Line Voltage)
  • output Voltage(V): 220V(Line Voltage)
  • Display: LCD
  • Warranty time: 12 months
  • Frequency & Range(Hz): 46Hz-54Hz, 56Hz-64Hz
  • Battery: 192VDC

Packaging & Delivery

Packaging Details Each Piece protected by styrofoam in a wooden carton
Delivery Time Shipping in 15 days after payment reach

IA series Single Phase Inbuilt Isolation Transformer Low Frequency UPS 6KVA

Product Description

Function & Features:

  1. Advanced DSP digital control technology;
  2. Large-screen LCD + LED in Chinese and English display;
  3. Dual AC input;
  4. Parallel machine functions;
  5. High loading capacity, shock stronger;
  6. Charging current available set;
  7. Intelligent battery management;
  8. Adaptive system frequency and phase sequence;
  9. Protection and alarming functions;
  10. Especially for banks, telecom, government, transportation, manufacturing;
  11. education, sensitive devices, etc.



Specification:

IA SERIES 3-20KVA  (Single Phase In Single Phase Out)
MODEL (1 Phase Input/1 Phase Output)IA3KIA6KIA10KIA15KIA20K
Input MainsRated Voltage(V)220V(Line Voltage)
Rated Voltage & Range(V)220V±25%
Frequency & Range(Hz)46Hz-54Hz, 56Hz-64Hz
Bypass InputRated Voltage(V)220V
Rated Voltage & Range(V)220V±25%
Frequency & Range(Hz)46Hz-54Hz, 56Hz-64Hz
OutputRated Power3KVA/2.4KW6KVA/4.8KW10KVA/8KW15KVA/12KW20KVA/16KW
Rated Voltage(V)220V(Line Voltage)
Rated Voltage & Stability200/208/220/230/240VAC Phase Voltage
THDVLinear Load≤3%
Non-linear Load≤8%
Output Power factor0.8(Lag)
Tracking Fruquency & Range(Hz)46Hz-54Hz, 56Hz-64Hz
Fruquency & Stability(Battery Inverter)(50±0.1)Hz, (60±0.1)Hz
Overload CapabilityLess than 105%±5% for overload alarm;
105%±5%~125%±5% for 2 minutes;125%±5%~150%±5% for 30 second;More than 150%±5% for 0.5 second;
Switching time (Normal mode)0ms
SystemSystem Efficiency(Linear Load)≥80%≥82%≥85%≥86%≥87%
DisplayLCD+LED
EMS/EMITransmission RadiationIEC EN62040-02
ImmunityIEC 61000-4-2.4.5 Level IV, IEC61000-4-3 Level III
Safety RequirementsGB4943-2001/IEC62040-1
Noise Level(1M)≤55dB
Isolate Impedance(Ω)>2M(500VDC)
Surge Current ProtectionIEC60664-1 IV
EnvironmentOperating Temperature0oC - 40oC
Elevation<1000m
Storing Temperature-15oC - 45oC
Operation Humidity20% - 95%
Battery192VDC
UPS Size(WxHxD)mm260x501x533260x717x560370x900x655
Package Size(WxHxD)mm390x640x680320x840x620450x1054x730
Net Weight(kg)405862155160
Gross Weight(kg)437680170175

Detailed Photos:

Packaging & Shipping

1.All of products have been tested by 3 times before ship out.

2.Support imprint your logo on products and let your logo shine anywhere.

3.OEM/ODM orders available.

4.We own the best after-sale service. If any problem happen, our team will do our best to solve it for you.

5.We can ship products to you by SEA,by AIR and by Courier.





Certifications



Buying Guides



Company Information



Shenzhen Zhongyuan Chuangda Technology Co. Ltd (ZYUPS), with our brand IWELL, was founded in 1997.We are a professional high-tech high precision and high quality enterprise with international trade experience specialized in the development manufacture sale and after-sales service of UPS (Uninterrupted Power System), solar inverter and Storage Lead Acid Battery.



To fit the varieties of customers and markets we offer Offline UPS ranges high frequency Low frequency Rack-mounted and line interactive UPS range. Home inverter, solar inverter with and without MPPT PMW controller.Our IWELL products have passed ISO9001 also with CE UL ROSH FCC certificate.



Innovative technology is our pursuit target. Our R&D center (research and development center) located in shenzhen. With first-class research and development conditions Strong R&D team research and development ability ensure that the products of advanced and innovative. continuously introduce more market competitive model to meet customers High reliability and high intelligent demands.



With the notion of "close to customer" we have aligned most of our resources to support our Original Equipment Manufacturer (OEM) customers and work with our customers as a power partner. Our mission is " faith cooperation pragmatic innovation and development " and to accomplish this we will continue to tailor products for market needs while maintaining high quality integrated customer service and prompt delivery.







FAQ

Q:What's the payment term?

A:We accept TT,30% deposit and 70% balance against copy of B/L;



Q:How is the delivery time?

A:Usually it will take about 25 working days for production;



Q:How is the standard of the package?

A:For the small capacity, it will use cartoon,for the big capacity,we should use the strong wooden case for protection;



Q:Would you accept our own logo?

A:If you have good quantity,it's absolutely no problem to do OEM;



Q:Could you tell me the month capacity?

A:It depends on the model,for example,the relay type small capacity,month capacity can reach near 20000pcs and big capacity near 30000pcs;



Q:Does the inverter connect with solar system?

A:Yes,because of the unique feature which combine invert,charge and ac auto-transfer switch into one complete system,made inverter not only connect with solar system,but also could used in officer equipment,household items,power tools etc.
